PART No | Designation | Dimensions | Hole D mm |
Weight Kg 1 / pcs kg |
|||
---|---|---|---|---|---|---|---|
A x B inch |
A mm |
B mm |
C mm |
||||
PH 10 | 260 x 260 x 40 / 4 x 50 | 10 | 260 | 260 | 40 | 4 x 50 | 3,0 |
PH 12 | 310 x 310 x 40 / 4 x 50 | 12 | 310 | 310 | 40 | 4 x 50 | 4,0 |
PH 14 | 360 x 360 x 40 / 4 x 50 | 14 | 360 | 360 | 40 | 4 x 50 | 6,0 |
PH 16 | 410 x 410 x 40 / 4 x 50 | 16 | 410 | 410 | 40 | 4 x 50 | 7,5 |
PH 18 | 460 x 460 x 40 / 4 x 50 | 18 | 460 | 460 | 40 | 4 x 50 | 9,0 |
PH 18 | 460 x 460 x 60 / 4 x 70 | 18 | 460 | 460 | 60 | 4 x 70 | 14,0 |
PH 21 | 540 x 540 x 60 / 4 x 70 | 18 | 540 | 540 | 60 | 4 x 70 | 21,0 |
PH 21 | 540 x 540 x 60 / 2x80+2x90 | 12 | 540 | 540 | 60 | 2x80+2x90 | 20,0 |
PH 21 | 540 x 540 x 80 / 4 x 70 | 12 | 540 | 540 | 80 | 4 x 70 | 28,5 |
PH 21/28 | 540 x 700 x 80 / 4 x 70 | 21 / 28 | 540 | 710 | 80 | 4 x 70 | 35 |
PH 24 | 610 x 610 x 60 / 4 x 70 | 24 | 610 | 610 | 60 | 4 x 70 | 29 |
PH 24 | 610 x 610 x 90 / 4 x 70 | 24 | 610 | 610 | 90 | 4 x 70 | 37 |
PH 24/32 | 610 x 810 x 90 / 4 x 70 | 24 / 32 | 610 | 810 | 90 | 4 x 70 | 51 |
PH 24/32 | 610 x 810 x 90 / 2x80+2x90 | 24 / 32 | 610 | 810 | 90 | 2x80+2x90 | 49,5 |
